System Requirements
- Windows® 7, Windows Vista® (SP2),Windows XP (SP3) , Intel® Pentium® or AMD Athlon™ 1.8 GHz (2.4 GHz or higher recommended)
- Intel Core™2 Duo 2.4 GHz required for AVCHD*, Intel Core2 Quad 2.66 GHz or Intel Core i7 required for AVCHD* 1920
- 1 GB system memory recommended, 2 GB required for AVCHD*
- DirectX® 9 or 10 compatible graphics card with 64 MB (128 MB or higher recommended)
- 256 MB required for HD and AVCHD*
- DirectX 9 or higher compatible sound card
- 3.2 GB of disk space
- DVD-ROM drive to install software
- 1 USB 2.0 port
- Optional:
- CD burner for creating Video CDs or Super Video CDs (S-VCDs)
- DVD burner for creating DVD and AVCHD* discs
- Sound card with surround sound output required for preview of surround sound mixes**
Input Options
- Capture from DV, HDV and Digital8 camcorders or VCRs
- Capture from analog camcorders, 8mm, HI8, VHS, SVHS, VHS-C, SVHS-C, or VCRs (NTSC/PAL/SECAM).
- Import from AVCHD* and other file based Camcorders, Digital Still Cameras, Mobile Devices and Webcams via USB
Output Options
- Output to DV, HDV or Digital8 tape (requires camcorder with FireWire® Input port)
- Output to analog videotape (requires DirectShow compatible device with video output)
Import Formats
- Video: AVCHD*, BD Blu-ray*, DV, HDV, AVI, MPEG-1, MPEG-2, DivX®*, MPEG-4*, 3GP(MPEG-4)*, WMV, Non-encrypted DVD titles (incl. DVD-VR/+VR), QuickTime® (DV, MPEG-4*, H.264*)
- Audio: MP3, MPA, WAV, AC3*, WMA
- Graphic: BMP, GIF, JPG, PCX, PSD, TGA, TIF, WMF, PNG, J2K
Export Formats
- AVCHD*, DVD (DVD-R, DVD-RW, DVD+R or DVD+RW, dual layer), S-VCD, Video CD (VCD)
- Apple® iPod®, Sony® PSP®/PS3™, Nintendo® Wii™, Microsoft® Xbox compatible formats*
- DV, HDV, AVI, DivX*, RealVideo® 8, WMV, MPEG-1, MPEG-2, MPEG-4*, Flash, 3GP*, WAV, MP3*, QuickTime® (SD format) files
- Dolby® Digital 2 channel and 5.1 channel** audio
* Requires free online product activation.
** Requires product activation via Internet at additional cost.
Hardware Specifications
Inputs & Outputs:
- Composite video input (RCA connector) PAL, SECAM, NTSC
- S-Video input (mini-DIN connector) PAL, SECAM, NTSC
- Stereo audio input (2 x RCA connectors)
- IEEE 1394 In/Out connector (6-pin type)
Analog Video Capture to Computer
- Analog PAL & SECAM/NTSC input
- HDV/DV (IEEE 1394) camcorder capture. Full camera control support
- Compression: MPEG-2, DV, MJPEG (User selectable. Available real-time capture formats depend on CPU speed.)
Video Playback from Computer
- HDV/DV (IEEE 1394) output to camcorder. Full camera/device control support
Product specifications are subject to change without notice or obligation.
